The Assembled Double Sided Printed Circuit Board is a high-quality FR4 copper clad electronic board designed for reliable circuit performance, compact routing and enhanced electrical stability. Built using durable FR4 epoxy glass laminate material with copper layers on both sides, this PCB provides improved circuit density compared to single layer boards. The assembled configuration allows immediate integration into electronic systems, making it suitable for industrial, educational and DIY electronics applications.
A double sided PCB enables routing traces on both top and bottom layers, reducing jumper wires and improving overall circuit efficiency. Copper cladding ensures excellent electrical conductivity while FR4 substrate provides high insulation resistance and mechanical strength. This makes the board ideal for low voltage and medium complexity electronic circuits, embedded systems, power control modules and prototyping tasks.
Designed for engineers, technicians and hobbyists across India, this pack of 1 PCB is suitable for repair, replacement or new project development.
This assembled double sided PCB is suitable for:
• Electronics engineers
• Repair technicians
• Robotics enthusiasts
• DIY electronics hobbyists
• Engineering students
• Industrial automation professionals
• Embedded system developers
• Educational labs and training institutes
If you are developing compact circuits requiring routing flexibility and stable signal transmission, this PCB is an ideal choice.
Unlike single sided boards, double sided PCBs allow routing on both surfaces, increasing component density and improving circuit layout flexibility. This reduces the need for external wiring bridges and improves signal clarity.
FR4 epoxy glass laminate offers excellent dielectric strength, flame resistance and mechanical durability. It ensures electrical safety and long operational life.
Copper traces provide efficient electrical conduction with minimal resistance. This improves signal integrity and power delivery across the circuit.
Assembled PCB saves time in component mounting and soldering. It is ready for integration into electronic systems.
FR4 material resists deformation under moderate heat, making it suitable for electronics operating in varying environmental conditions.
• Double sided copper clad construction
• FR4 epoxy glass substrate
• Pre-assembled electronic configuration
• High insulation resistance
• Compact circuit routing capability
• Durable solder mask protection
• Suitable for low to medium power electronic circuits
• Ideal for prototyping and repair
Inspect the PCB for visible damage before installation.
Identify input and output terminals as per circuit requirement.
Integrate the board into your enclosure or system housing.
Ensure correct voltage and current ratings are followed.
Secure mounting using non-conductive spacers.
Perform functional testing before full operation.
If modifying the circuit, use temperature-controlled soldering equipment to prevent trace damage.
• Avoid bending the PCB to prevent micro cracks in copper traces.
• Store in anti-static packaging when not in use.
• Keep away from moisture to prevent oxidation.
• Avoid excessive heat exposure.
• Clean gently using isopropyl alcohol if flux residue is present.
• Handle edges carefully to avoid electrostatic discharge.
Proper care ensures long life and reliable circuit performance.
